Enabling the world’s smallest giga-factories
DWFritz’s next-generation electrode stacking system eliminates the limitations of the current Z-Fold stacking method, and saves millions of dollars in annual operating costs. This paradigm shattering machine notches, cuts, and stacks complete electrodes at 0.2 sec/electrode.
Sounds too good to be true, right? Get in touch to learn more.
Key Features
- Throughput – World’s fastest stacking engine (0.2 sec/electrode*)
- Footprint – 70% reduction in floor space
- Precision – Sub 10μm electrode placement
- Quality – Inline stacking inspection & traceability through realtime digital twin
- Flexibility – Multiple cell formats and battery chemistries
- ROI – Greater than 80% reduction in annual operating costs
* Electrode = anode or cathode + separator
Ready to see behind the curtain?
Key Specifications
| Throughput | 0.2 sec/electrode* |
| Footprint | ~20m2 (stacker + feeder) |
| Precision | < 100 micron stack and electrode-to-electrode alignment |
| Quality | Vision & laser based inspection Digital twin traceability Inline defect detection |
| Flexibility | Liquid & solid electrolyte chemistries Multiple cell formats on a single engine |
| Integration | Inline notching and process control |
